Gold Recovery, Gold mining
ECO-GOLD: It’s our pride.Design as a carbon solution for mainly gold recovery and other mining industries. ECO-GOLD is produced by natural STEAM ACTIVATION of virgin COCONUT SHELL CHARCOAL. Resulting on unique patterned pores, offers excellent adsorption with reduced leaching and less platlet content, enhancing better recovery of gold and other minerals.
MINING & GOLD RECOVERY
The best-known application for activated carbons in the mining sector is for the extraction and recovery of gold (Au), although it is also used for some other precious metals.
Activated carbon has been used for gold recovery in the gold mining industry commercially for decades. The high specific surface area and porosity, good affinity to aurocyanide ions (that is gold ions):, and abundant resources make activated carbon an efficient and economical material for the adsorption of aurocyanide. However, the separation of activated carbon from the slurry is usually a challenge, and the adsorption rate of activated carbon is limited by the coarse particle size. Activated carbon adsorbs the gold particles and lets the rest of the slurry pass through. Eco Carbon CCC, SRL provides best in class of product series of Activated Carbon that can used in gold mining industry.
CHARACTERISTICS OF ACTIVATED CARBON FOR GOLD RECOVERY
There are various types of activated carbon within the field of gold for different applications with unique characteristics.Adsorptive Capacity (known as K-value): This refers to how much the activated carbon can absorb.
Adsorption Rate (known as R-value): The rank of adsorption is influence by physical and chemical properties of the activated carbon
Mechanical Strength and Abrasion Resistance/Hardness: Using the mechanical strength to reduce the losses from attrition which can cause carbon loss and cause the loss in recoverable gold
Particle Size Distribution: It is another key factor in choosing activated carbon for gold recovery which linked to the adsorption rate.
Platelets: It is important, which control lose of activated carbon while using in the commercial application.
List of Products
| Specification | Test Method | Metal Recovery-Gold Carbon | ||
|---|---|---|---|---|
| Grade | ASTM D 2862 | 6x12 | 6x16 | 8x16 |
| Plus (%) | ASTM D 2862 | 5% max | 5% max | 5% max |
| Minus (%) | ASTM D 2862 | 5% max | 5% max | 5% max |
| CTC(%) | ASTM D 3467 | 45-60 | 45-60 | 45-60 |
| Surface Area,(m2/g) | BET | 950-1150 | 950-1150 | 950-1150 |
| Moisture (%) | ASTM D 2867 | 4% max | 4% max | 4% max |
| Ash (%) | ASTM D 2866 | 4% max | 4% max | 4% max |
| Platelet Content (%) | ANGLO GOLD | 4% max | 4% max | 4% max |
| Ball Pan Hardness (%) | ASTM D 3802 | 99 min | 99 min | 99 min |
| Apparent Density (Kg/m3) | ASTM D 2854 | 520 +/- 30 | 520 +/- 30 | 530 +/- 30 |
| Ph | ASTM D 3838 | 9 to 11 | 9 to 11 | 9 to 11 |
Available typical activity range:
• CTC activity % : 45 - 60• Surface area M2/g : 950-1150 m2/g
• Pore volume: 0.45 - 0.65 cm3/g
• R-Value: 45 - 55 %
• K-Value: 18 - 30 kg/mt
